Capture Product Development has the following in-house capabilities:

Mechanical

  • Solidworks Mechanical CAD
  • 3D Printing
  • CNC machining
  • Many prototyping fabrication functions such as drilling, tapping, grinding, finishing and painting.
  • Optics prototyping

Electronics

  • Electronics Schematic CAD
  • Electronics Testing and Verification
  • Electronics Gerber generation
  • Electronics Prototyping / Bread-Boarding
Capture has 3-axis milling capabilities in-house. It's one more method we use to create prototypes, test fixtures or small production runs for our customers. We partner with excellent manufacturers for large volume work, transitioning completely out of the picture after the product is established and stable.Capture has 3-axis milling capabilities in-house. It's one more method we use to create prototypes, test fixtures or small production runs for our customers. We partner with excellent manufacturers for large volume work, transitioning completely out of the picture after the product is established and stable.
Capture offers 3D printing in-house. For Rapid-Prototyping fabrication technologies which we don't have in-house, we have special arrangements with partners who supply such services at the lowest cost for you.Capture offers 3D printing in-house. For Rapid-Prototyping fabrication technologies which we don't have in-house, we have special arrangements with partners who supply such services at the lowest cost for you.
Shown are two prototype enclosures for Bandspeed, being prepped for painting.Shown are two prototype enclosures for Bandspeed, being prepped for painting.
Talk to us about adding Zigbee wireless sensor networking and controls to your product line.Talk to us about adding Zigbee wireless sensor networking and controls to your product line.
Capture offers electronics design, sourcing and prototyping. Shown here is an early version of the Evergreen Telemetry Wrist Reporter product.Capture offers electronics design, sourcing and prototyping. Shown here is an early version of the Evergreen Telemetry Wrist Reporter product.
CapturePD possesses expert-level knowledge and capabilities in CFD analysis. We use the Cosmos FEA/CFD suite to design thermal and stress/strain solutions. Non-linear systems and radiation effects are part of our capabilities.CapturePD possesses expert-level knowledge and capabilities in CFD analysis. We use the Cosmos FEA/CFD suite to design thermal and stress/strain solutions. Non-linear systems and radiation effects are part of our capabilities.
Capture possesses expert-level CFD analysis knowledge and capabilities. Ask us about how we would tackle existing or anticipated thermal issues for your product.Capture possesses expert-level CFD analysis knowledge and capabilities. Ask us about how we would tackle existing or anticipated thermal issues for your product.

Analysis

  • Thermal and Stress/Strain Numerical Analysis (CFD, FEA)

Wireless Sensor-Area-Network Integration (Zigbee)

  • We add WSAN functionality to your product line for a brand new revenue stream.  Your products can be made to transmit relevant data or be controlled wirelessly.

Manufacturing / Assembly / Sourcing

We provide manufacturing services through a network of partners.  Although many of our partners are here in the US, we service high-volume customers with our partner facilities in Malaysia.  Click on the pictures below to learn more about our facilities overseas.

Chris and the engineering and management team in Malaysia.Chris and the engineering and management team in Malaysia.
A shot of Penang, Malaysia, the location of our manufacturing partners.A shot of Penang, Malaysia, the location of our manufacturing partners.
LK and Anne are two of the brains behind the operations. They perfect processes, build and orchestrate quality plans and lead the technicians during their assembly work.LK and Anne are two of the brains behind the operations. They perfect processes, build and orchestrate quality plans and lead the technicians during their assembly work.
Loke and LK discuss a laser sub-assembly process.Loke and LK discuss a laser sub-assembly process.
The first batch of laser sub-assemblies through the officially released assembly process.The first batch of laser sub-assemblies through the officially released assembly process.
Loke and LK inspect receive diodes during the adhesive process development.Loke and LK inspect receive diodes during the adhesive process development.
